| 形式 |
HCS400-A
Dry battery |
HCS400-B
Charge up batter |
HCS50-A
Dry battery |
HCS500-B
Charge up battery |
| 分辨率 |
Current mode |
mA表示indication:0.01mA(Span<20mA)
%表示indication:0.1% |
| Vottage mode |
-- |
V表示indication:0.01V
%表示indication:0.1% |
|
输入·输出范围
|
Source mode |
0-20.5mA(-25-103%) |
电流 Current:0-20.5mA(-25-103%)
电压 Voltage:0-5.12V(-25-103)% |
| Read mode |
0-20mA(-25-103%) |
| 2-Wire mode |
0-20.5mA(-25-103%)/回路电压极限5-40VDC |
| 输出能力 |
Current mode |
Standard mode 500欧姆Max/High mode 750欧姆Max |
| Voltage mode |
-- |
Max 10mA（500欧姆 at 5v output） |
| 输出设定 |
0.01step:up/down key |
0.01mA |
电流 Current:0.01mA
电压 Voltage:0.01V |
25%step:25%
step key |
电流：CURRENT:4,8,12,16,20mA(0,25,50,75,100%)
|
| -- |
电压Voltage:1,2,3,4,5V
(0,25,50,75,100%) |
over range:
UNDER/OVER key |
电流：CURRENT/UNDER：2mA(-12.5%),OVER:20.5mA(103%) |
| -- |
电压：CURRENT/UNDER：0.5V(-12.5%)
/ OVER:5.12V(103%) |
